Тарг С.М. 1989 С2 вариант 20

The structure consists of a rigid angle and a rod, which at point C are either hinged to each other or freely resting on each other. The structure is acted upon by: a pair of forces with a moment M=60 kNm, a uniformly distributed load with intensity q=20 kN/m and two forces. Determine the bond reactions at points A, B, C. For final calculations, take a=0.2m.
Given: K:F₁= 10kN; α₁= 60⁰; H: F₃ = 30kN; α₃ = 30⁰; C.L.
