Проект СКС диспетчерского пункта

The working design of the control center SCS provides for:
• implementation of cable wiring (telephone and local area network) based on the technology of structured cabling systems (SCS) in accordance with the international standard for cable systems ISO/IEC 11801 using cables and switching equipment of category 5;
• cable troughs (trays) required for laying LAN and telephone network cables (in the premises, it is provided for laying shielded twisted pair cables Gigatek S-FTP 4x2x0.5 in the outer compartments of the decorative cable channel provided for in section 3455-KS08-9-EL);
• installation in the "Equipment Room" of an MDF distribution (mounting) cabinet for placing passive SCS equipment in them, as well as LAN equipment;
• placement in the MDF mounting cabinet of the following passive SCS equipment:
- fiber-optic patch panel;
- RJ-45 patch panels (STP);
- telephone cross;
- devices for distributing patch cords.

File format: dwg, tif (AutoCAD 2010 not editable)
Note: source files of *.tif format must be in the same folder with the project file *.dwg

Download file "Project of SCS of control center" >>>

Tags: gas compressor station, control center
