Проект установки пробоотборников

Detailed design for installation of samplers on fuel oil tanks.
Installation on oil tanks of stationary sampling systems with a measuring hatch, type KZP-10-01.
Compound:
- Common data.
- Schematic diagram of the supply and recirculation of fuel oil in tanks.
- Layout plan of the designed equipment at the fuel oil pump station.
- Scheme of installation of stationary sampling systems at the MB.

Format - DWG compatible with AutoCAD 2004-2017, Compass, ZWCAD, nanoCAD, BricsCAD, etc.
