Теплоизоляция горизонтального резервуара

Detailed design for the thermal insulation of a horizontal tank / heat exchanger.
Thermal insulation of fuel oil heater.
Thermal insulation of the fuel oil heater and pipelines is provided in order to comply with the standards for temperature on the insulation surface - not higher than 45 ˚С.
Thermal insulation - mineral wool mat MINWATT, thickness 50 mm. GOST 19904-90 galvanized steel is used as the covering material of the insulation surface.
Installation drawings and bill of materials.

Format - DWG compatible with AutoCAD 2004-2017, Compass, ZWCAD, nanoCAD, BricsCAD, etc.
