Наружные сети канализации техникума

External sewerage networks of the technical school
Section of the working project on the external sewerage networks of the educational buildings of the technical school.
RD composition:
- Common data.
- Plan of networks K1, K3.
- Layout plan for fire hydrants PG-1, PG-2.
- Sewerage scheme.
- Profile of networks K1, K3.
- Scheme of construction of wells, systems K1, K3, B0.
- Table of wells K1, K3, B0.
- Drawing of the structure of the waterproofing of the wells.
- Drawings of the construction of a cesspool of 10 m3 (intended for collecting domestic wastewater).
- Specification of equipment, products and materials.

Format - AutoCAD 2010 DWG.
