МГСУ, Металлические конструкции, включая сварку 05В

Option 05
MGSU University, ASG - teacher Vershinin.
Metal structures, including welding - One-story industrial building.
Term paper was handed over to this teacher.
The content of the work:
Building layout
Calculation of the crane beam
Calculation of the frame load CSF table
Column calculation
Calculation truss truss

Drawing sheet 1:
Contains building layout, column, sections
Drawing sheet 2:
Truss farm
---------------------------------------
Archive contains:
Drawings in .dwg .pdf format; Explanatory note in .doc format.
For all questions arising in the PM contact.
