Одноэтажное трехпролетное здание 120х108м (DWG)

The main carrier profile Welded Beams with corrugated wall, the production of "Firma METAKOM".
The rigidity of the frame provides a rigid conjugation columns with foundations; hard covering conjugation beams with columns;
system of vertical struts and ties on the columns, as well as the communication system of the roof beams and girders cover.
Foundations - tape, in the form of monolithic belts under the column frame.

1 file - editable format DWG (containing 10 sheets of A1 and 5 sheets of A2). Foundations.
1 file - editable format DWG (5 sheets of A1 and 16 sheets of A2). Steel frame.
