Чертеж "Теплообменник кожухотрубчатый"

Drawing "Shell-and-tube heat exchanger"

Technical specifications
1. Pipe space:
- Name: Toluene
- Toxicity: Toxic
- Explosive: Explosive
- Aggressiveness: Aggressive
- Temperature, °С: 110
- Working pressure, MPa: 0.2
- Capacity, m3: 0.36
2. Annulus:
- Name: Water
- Toxicity: Non-toxic
- Explosion hazard: Non-explosive
- Aggressiveness: Non-aggressive
- Temperature, ° С: 143
- Working pressure, MPa: 0.4
- Capacity, m3: 0.50
3. Heat exchange surface, m2: 49

Content:
- Heat exchanger. General view drawing (KOMPAS-3D)
